China 20/40FT Expandable Prefabricated Modular Steel Structure Portable Construction Prefab Mobile Shipping Container House Camp House
PRODUCT INFORMATION
Lida modular container camp house has excellent security thanks to its high-quality materials and strong modular construction.
This prefabricated accommodation container is designed to provide the ultimate safety, convenience, and healthy living spaces for workforces across many industries such as construction and mining. Moreover, the design of the prefab accommodation container makes the building fire-resistant and affords protection against earthquakes and floods. Finally, it is fitted with multiple eco-friendly features, which makes it an ideal choice of infrastructural solution with a view to protecting the environment.
Component Specification of Lida Integrated Labor Camp ( prefab house type)
|
Type |
With or without steel chassis |
Type one: without steel chassis, build on a concrete strip foundation Type two: with steel chassis, the building will be put on concrete blocks |
|
Story |
One story or two story or three storeys are available |
|
|
Frame system |
Steel column |
Q235 Steel, 100*100*2.5 square tube, alkyd paint, twice primer paint & twice finish paint |
|
Steel roof truss |
C100*40*15*2.0, welding and galvanized |
|
|
Roof and wall purlin |
C100*40*15*2.0, galvanized |
|
|
Cross bracing |
Q235 Steel, L40*3 angle steel, alkyd paint, twice primer paint & twice finish paint |
|
|
Chemical bolt |
M16, chemical bolt |
|
|
Ordinary bolt |
4.8S galvanized |
|
|
Steel chassis or 1st floor system |
Main beam |
HN250*125*5.5*8, Q235 Steel, alkyd paint, twice primer paint & twice finish paint |
|
Secondary beam |
C100*40*15*2.0 galvanized |
|
|
Floor structure board |
18/20mm plywood and fiber cement board |
|
|
Flooring |
PVC floor leather and ceramic tiles are available |
|
|
Wall and Roof system |
Wall panel |
Sandwich panel: Rock wool, Glass wool, EPS, and PU are available Thickness: 50mm, 75mm, 100mm, 150mm, and 200mm are available |
|
Roof panel |
Sandwich panel: Rock wool, Glass wool, EPS, and PU are available Thickness: 50mm, 75mm, 100mm, 150mm, and 200mm are available |
|
|
Ceiling system |
Dry room |
600*600*6mm gypsum board, with framework |
|
Wet room |
600*600*5mm calcium silicate board, with a framework |
|
|
Door and window system |
Door |
Fire resistant steel single/double door, emergency door with a panic bar, aluminum glass door, and MDF door are available |
|
Window |
PVC, Aluminum sliding window with single/double glazed glass, mosquito screen, with louver are available |
|
|
Electric and Plumbing system |
Electric units |
Electric wire, conduit, socket, switch, light, distribution box |
|
Sanitary units |
Shower, closestool, basin, water pipe |
Typical drawings of Lida China 20/40FT Expandable Prefabricated Modular Steel Structure Portable Construction Prefab Mobile Shipping Container House Camp House
Specification of Lida China 20/40FT Expandable Prefabricated Modular Steel Structure Portable Construction Prefab Mobile Shipping Container House Camp House
